DESCRIPTION

Basic Info

Model NO.	HD-Fiber converter
Fiber Core	Single Fiber
Channels	4 Channels
Distance	Max 80km
Rack Mount	Support
Transport Package	Carton
Trademark	HCSTCOM
Origin	Wuhan Optical Vally, China
Production Capacity	100000 PCS/Year

Product Description

Overview

Quick Details

Model Number:

HC3040DA-3G-T/R

Place of Origin:

Beijing, China

Brand Name:

HCSTCOM

Product name:

Fiber Media Video Converter

Supply Ability

Supply Ability
5000 Pair/Pairs per Week

Packaging & Delivery

Packaging Details
Carton
Dimension: 173mm (H) *276mm (D) *40.6mm (W)
Weight:2KG
Port
Beijing Wuhan
Picture Example:
Lead Time:

Quantity(Pairs)	1 - 1000	>1000
Est. Time(days)	4~6	To be negotiated

Introduction

16-Ch 3G-SDI with 16-ch external Audio, 16-ch reverse RS485, single mode, single fiber, FC/PC fiber connector, BNC video interface, 0-80km, stand-alone or 1U rack mount

The HC3040DA-3G could transmit 3G/HD/SD-SDI as per 424M/425M (SDTi), SMPTE 310M (19.4Mb/s), SMPTE 344M (540Mb/s),M2S and DVB-ASI (270Mb/s) standard, with or without embedded audio and data, as well as DVB-ASI over one single mode or multimode fiber. Signals are equalized and re-clocked prior to fiber optic transmission. The transmitter features a re-clocked and equalized SDI looping out; the receiver features two re-clocked and equalized SDI outputs.

Main Features

«2~48ch unidirectional 3G/HD-SDI video with embedded audio over one fiber, compatible with ASI, TS stream

«Range from 19.4Mb/s to 2.97Gb/s

«SDI pathological signal is optional, clock recovery

«Support SMPTE 424M/425M (SDTi), SMPTE 310M (19.4Mb/s), SMPTE 344M (540Mb/s),M2S and DVB-ASI (270Mb/s) standard

«Output wavelength 1310nm,1550nm and 16 types of CWDM (ITU-T G.694.2 compliant)

«100m automatic cable equalization, all the 2.97 Gb/s rate below(Belden 1694A)

«Optional network management system

«LED status indicators monitor the critical parameters

«Support hot swap

«Support stand-alone, 1U rack mount and 4U rack mount

Specifications

Serial TV BNC Input
TV signal standard	SMPTE 425M, 292M, 259M, 297M, 305M, 310M, 424M, M2S, DVB-ASI, DVB-SSI and other Telecom/Datacom rate (19.4Mb/s - 2.97Gb/s)
Input channel	2~48
Reflection loss	>15DB
Equilibrium	0-100m @ 2.97Gb/s
Connector	75Ω BNC

Serial TV BNC Output (EO/OE)
No. of channels	2~48
Signal level	800mV nominal
Rise/fall time	200Ps nominal
Overshoot	<10% amplitude
Reflection loss	> 15dB
Jitter	< 0.3UI
Connector	75Ω BNC

Audio
Channel	2~48 (unidirectional)
Input/output level	2Vp-p max
Total harmonic distortion	≤1%
Audio encoding	24-bit
Bandwidth (-3 dB)	20~15 KHz
Input/output impedance	100KΩ (600Ω optional)
Differential gain	≤1.5%
Differential phase	≤1°
Weighted SNR	≥70 Db
Connector	Terminal Block with Screw Clamps

Power and environmental indicator
Operating temperature	-40ºC~+50ºC
Pressure	220 to [email protected]
Power	12W
EMI/RFI	FCC Part 15 Class A, EU EMC standard
Average time trouble-free	>100000 hours

Optic Output
Channel	1
Type	Single-mode/fiber
Wavelength	1310nm /1550nm
Reflection loss	> 15dB
Jitter	< 0.3UI
Connector	FC/PC(SC/PC optional)

Data
Channel	2~48
Data format	Reverse RS-485, RS422 is optional
Data rate	DC to 100 Kb/s
Mode	Full/half duplex
Connector	wire connecting terminal

Ethernet(optional)
Channel	1 RJ45
Bandwidth	3Kg

Other
Dimension	1U 2U 3U
Weight	10Mbps/100Mbps

Applications

«Remote OB Van/Truck Video Feeds

«Broadcast Studio Camera Feeds

«Long-haul Signal Transport

«TV station/video conference

«Lecture Hall Projector Connectivity

«Medical/Surgical Room Broadcast

«Building to Building video conference calling

«Small corporate campus video links
