DESCRIPTION

Basic Info

Certification	RoHS, CE
Condition	New
Usage	Radio, Television
Information Content	Text, Picture, Video, Audio
Type	Optical
Model No.	Hc100h
Control	Wired
Interface Type	HDMI
Distance	70-150m
Rack Mount	Support
OEM & ODM	Available
Resolution	4K/70m, 1080P/150m
Feature	Real Time, Uncompressed
Function	Signal Transmission
Transport Package	Carton
Trademark	HCSTCOM
Origin	Beijing, China
Production Capacity	100000 PCS/Year

Product Description

1. Product Name Cable Extender over Twisted Pair Cable 70-150M

2. Description

HDBaseT HDMI Extender over cat6 extends HDMI and IR signals to remote places. 1080P up to70 meter with normal 8 core cat5e/6/7 cable with high quality cables from top brands.4K*2K Up to 30 meter with normal 8 core cat5e/6/7 cable, with high quality cables from top brands.High bandwidth, no loss, no delay, plays real time HD video at remote places. Widely used in computing and surveillance systems, big screen advertisement system, video wall, bank, stock market, education system etc

3. Main Features

Incorporates HDBaseT technologySupport resolution up to Ultra HD 4Kx2K Transmission distance [email protected]/30m,1080p/70mSupport 3DHDCP 1.3 compliantCEC pass throughSupport wide-band Bi-directional IR (38KHZ to 56KHZ)IR extension from transmitter to receiver or from receiver to transmitterSupport 3U rack mount for insert card

4. Specifications

Items	Specification
Transmitter	1*HDMI in, 1*HDBaseT RJ45,1*IR in, 1*IR out (RS232 optional)
Receiver	1*HDMI out, 1*HDBaseT RJ45,1*IR in, 1*IR out (RS232 optional)
HDMI input resolution supported	DTV/HDTV 4K/1080P/1080i/720P/720i/576P
HDMI output resolution supported	Support DTS-HD, Dolby-HD (Repeater the source to the sink)
IR remote control	Support bidirectional infrared signal return
HDMI compliance	HDMI 1.4
HDCP compliance	HDCP 1.3
Transmission length	Max 4Kx2K/30m,1080p/70m
Transfer method	Over cat6
Connector	RJ45
Voltage/Current	DC12V/1A
Power Consumption	TX:2.5 Watts RX: 5 Watts
Power Supply	TX and RX both have external power adapter
Working temperature	-25~65ºC
Humidity (no condensation)	5%~90% RH
Dimension	96(L)x70(W)x24(H)mm
Gross Weight(transmitter and receiver)	1KG
Mean time between failures (MTBF)	>30000 Hours





5. Application

Digital FPDs, PDPs and projectors for medical appliances, aero, traffic control, factory, and bank
Digital FPDs and projectors in conference room and auditorium
Kiosk with digital FPDs showing full motion graphic displays from remote systems
PDP displays for information in public sites
LED signboards in streets and in stadiums
